AMD Radeon 9700 AI PRO (gfx1201) — vLLM Toolbox/Container

An fedora-based Docker/Podman container that is Toolbx-compatible (usable as a Fedora toolbox) for serving LLMs with vLLM on AMD Radeon R9700 (gfx1201). Built on the TheRock nightly builds for ROCM.

---

Table of Contents

• Tested Models (Benchmarks)
• 1) Toolbx vs Docker/Podman
• 2) Quickstart — Fedora Toolbx
• 3) Quickstart — Ubuntu (Distrobox)
• 4) Testing the API
• 5) Use a Web UI for Chatting

Tested Models (Benchmarks)

View full benchmarks at: https://kyuz0.github.io/amd-r9700-vllm-toolboxes/

Run benchmarks now include a comparison between the default Triton backend and the optional ROCm attention backend.

Table Key: Cell values represent Max Context Length (GPU Memory Utilization).

Model	TP	1 Req	4 Reqs	8 Reqs	16 Reqs
meta-llama/Meta-Llama-3.1-8B-Instruct	1	127k (0.98)	127k (0.98)	127k (0.98)	127k (0.98)
	2	105k (0.98)	105k (0.98)	105k (0.98)	105k (0.98)
openai/gpt-oss-20b	1	131k (0.98)	131k (0.98)	131k (0.98)	131k (0.98)
	2	131k (0.95)	131k (0.95)	131k (0.95)	131k (0.95)
RedHatAI/Qwen3-14B-FP8-dynamic	1	41k (0.98)	41k (0.98)	41k (0.98)	41k (0.98)
	2	41k (0.95)	41k (0.95)	41k (0.95)	41k (0.95)
cpatonn/Qwen3-Coder-30B-A3B-Instruct-GPTQ-4bit	1	151k (0.98)	151k (0.98)	151k (0.98)	151k (0.98)
	2	262k (0.98)	262k (0.98)	262k (0.98)	262k (0.98)
cpatonn/Qwen3-Next-80B-A3B-Instruct-AWQ-4bit	2	156k (0.98)	156k (0.98)	156k (0.98)	156k (0.98)
RedHatAI/gemma-3-12b-it-FP8-dynamic	1	45k (0.98)	45k (0.98)	45k (0.98)	45k (0.98)
	2	126k (0.98)	126k (0.98)	121k (0.95)	121k (0.95)
RedHatAI/gemma-3-27b-it-FP8-dynamic	2	60k (0.98)	60k (0.98)	60k (0.98)	60k (0.98)

Advanced Tuning

See TUNING.md for a guide on how to enable undervolting and raise the power limit on AMD R9700 cards on Linux to improve performance and efficiency.

🆕 Update: Comparison of Attention Backends (Triton vs ROCm)

Added Support for ROCm Native Attention Backend

I have added the ability to switch between the default Triton backend and the experimental ROCm native backend for attention operations. This provides you with more flexibility to optimize for stability or throughput depending on your specific model and workload.

Backend	Stability	Throughput	Compatibility
Triton (Default)	✅ High	🔸 Good	Works with all tested models
ROCm	⚠️ Experimental	🚀 Highest	May fail with complex architectures

Key Differences:

• Triton: The safe choice. It uses the Triton compiler to generate kernels and is the standard for vLLM on AMD.
• ROCm: Uses composable kernel based attention. In my benchmarks, this often yields higher throughput (tokens/sec) but can be less stable, leading to crashes or "invalid graph" errors on some newer models.

How to Use:

1. Easy Mode: Select the backend in the start-vllm wizard (Item 5 in the menu).
2. Manual Mode: Export the following environment variables before running vllm serve:

   export VLLM_V1_USE_PREFILL_DECODE_ATTENTION=1
   export VLLM_USE_TRITON_FLASH_ATTN=0


---

1) Toolbx vs Docker/Podman

The kyuz0/vllm-therock-gfx1201:latest image can be used both as:

• Fedora Toolbx (recommended for development): Toolbx shares your HOME and user, so models/configs live on the host. Great for iterating quickly while keeping the host clean.
• Docker/Podman (recommended for deployment/perf): Use for running vLLM as a service (host networking, IPC tuning, etc.). Always mount a host directory for model weights so they stay outside the container.

---

2) Quickstart — Fedora Toolbx

Create a toolbox that exposes the GPU and relaxes seccomp to avoid ROCm syscall issues:

toolbox create vllm-r9700 \
  --image docker.io/kyuz0/vllm-therock-gfx1201:latest \
  -- --device /dev/dri --device /dev/kfd \
  --group-add video --group-add render --security-opt seccomp=unconfined

Enter it:

toolbox enter vllm-r9700

Model storage: Models are downloaded to ~/.cache/huggingface by default. This directory is shared with the host if you created the toolbox correctly, so downloads persist.

Serving a Model (Easiest Way)

The toolbox includes a TUI wizard called start-vllm which includes pre-configured models and handles launch flags. It also allows you to select the experimental ROCm attention backend. This is the easiest way to get started.

# if your weights live on disk instead of on HuggingFace, point the
# launcher at the directory that contains the model folders.  the
# script will look for a subdirectory matching the repo ID and use it
# when launching.
export LOCAL_MODEL_DIR=/workspace/models
start-vllm

# you can also just run the CLI yourself and pass the path directly:
vllm serve /workspace/models/cpatonn/Qwen3-Coder-30B-A3B-Instruct-GPTQ-4bit ...

Cache note: vLLM writes compiled kernels to ~/.cache/vllm/.

---

离线/本地模式

如果你希望完全禁用网络访问，只使用本地权重，可以利用 LOCAL_MODEL_DIR。 脚本会在该目录下查找模型子目录；找不到时会立即报错并退出， 不会尝试下载任何内容。适用于没有外网或受限环境的部署。

export LOCAL_MODEL_DIR=/workspace/models
start-vllm            # 本地模式，如果模型缺失则失败

离线/本地模式

如果你希望完全禁用网络访问，只使用本地权重，可以利用 LOCAL_MODEL_DIR。 脚本会在该目录下查找模型子目录；找不到时会立即报错并退出， 不会尝试下载任何内容。适用于没有外网或受限环境的部署。

export LOCAL_MODEL_DIR=/workspace/models
start-vllm            # 本地模式，如果模型缺失则失败

3) Quickstart — Ubuntu (Distrobox)

Ubuntu’s toolbox package still breaks GPU access, so use Distrobox instead:

distrobox create -n vllm-r9700 \
  --image docker.io/kyuz0/vllm-therock-gfx1201:latest \
  --additional-flags "--device /dev/kfd --device /dev/dri --group-add video --group-add render --security-opt seccomp=unconfined"

distrobox enter vllm-r9700

Verification: Run rocm-smi to check GPU status.

Serving a Model

Same as above, you can use the start-vllm wizard to launch models easily.

start-vllm

---

4) Testing the API

Once the server is up, hit the OpenAI‑compatible endpoint:

curl -X POST http://localhost:8000/v1/chat/completions \
  -H "Content-Type: application/json" \
  -d '{"model":"Qwen3-Coder-30B-A3B-Instruct-GPTQ-4bit","messages":[{"role":"user","content":"Hello! Test the performance."}]}'

You should receive a JSON response with a choices[0].message.content reply.

If you don't want to bother specifying the model name, you can run this which will query the currently deployed model:

MODEL=$(curl -s http://localhost:8000/v1/models | jq -r '.data[0].id') curl -X POST http://localhost:8000/v1/chat/completions \
  -H "Content-Type: application/json" \
  -d "{
    \"model\": \"$MODEL\",
    \"messages\":[{\"role\":\"user\",\"content\":\"Hello! Test the performance.\"}]
  }"

---

5) Use a Web UI for Chatting

If vLLM is on a remote server, expose port 8000 via SSH port forwarding:

ssh -L 0.0.0.0:8000:localhost:8000 <vllm-host>

Then, you can start HuggingFace ChatUI like this (on your host):

docker run -p 3000:3000 \
  --add-host=host.docker.internal:host-gateway \
  -e OPENAI_BASE_URL=http://host.docker.internal:8000/v1 \
  -e OPENAI_API_KEY=dummy \
  -v chat-ui-data:/data \
  ghcr.io/huggingface/chat-ui-db
